This article introduces the setting method of "Wiegand output time interval setting", which is suitable for scenarios where you need to adjust the "communication method/Wiegand" related parameters or scan the corresponding configuration barcode.
Applicable to:
F16, F18W, K20, K28, L5, L5S, L8, L8BL, L8BLS, L8S, M60, M80, NT-1228BL, S5, S8, Z2S, C750, W22, W28, DS8100, DS2800, DS7500, DS8500, H8, M5, M5S, M8BT, M8BTS, NT-91
Questions
- How to set the Wiegand output interval?
- Where is the Wiegand output time interval configuration barcode?
- How to adjust the Wiegand output time interval parameter?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
According to the time to be set, scan the corresponding coefficient (two-digit configuration barcode), and add 0 in front of the missing digits. Default: 800us, unit: 100us, range: 100-1000us. For example, to set 100us and the coefficient is 01, you need to scan two digits to set the code "0" and "1". Set 1000us, the coefficient is 10, then you need to scan two digits to set the code "1" and "0".
Wiegand output time interval
Scan the following barcode for the Wiegand output time interval.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
