This article explains how to configure duplicate code detection and is intended for locating the corresponding configuration barcode and adjusting the parameter.
Applicable to:
C740, E740, F1900, F20, K6, L3, L6BL, L3S, L6BLS, L6S, NT-2100, R3L, S3, S6, H3, M20, NT-1228BC, W6, W6-X, Z3S
Questions
- How to set duplicate code detection?
- Where is the duplicate code detection configuration barcode?
- How to adjust duplicate code detection parameters?
Resolution / Answer
This setting controls duplicate code detection. It is usually used when you need to prevent repeated output of the same barcode within a short interval or find the corresponding configuration barcode.
Duplicate code detection settings
Turn off duplicate code detection*
Enable duplicate code detection
Scan the following barcode to enable duplicate code detection.
The repeat code interval is 1s
Scan the following barcode. The interval between re-codes is 1 second.
The repeat code interval is 2s
Scan the following barcode. The interval between repeated codes is 2 seconds.
The repeat code interval is 3s
Scan the following barcode. The interval between re-coding is 3 seconds.
The repeat code interval is 5s
Scan the following barcode. The interval between re-coding is 5 seconds.
The re-code interval is 10s
Scan the following barcode. The interval between re-coding is 10 seconds.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
