This article introduces the setting method of "Slave Station Address Settings", which is suitable for scenarios where you need to adjust the relevant parameters of "Communication Mode/Modbus Rtu Networking Function" or scan the corresponding configuration barcode.
Applicable to:
F16, F18W, K20, K28, L5, L5S, L8, L8BL, L8BLS, L8S, M60, M80, NT-1228BL, S5, S8, Z2S, C750, W22, W28, DS8100, DS2800, DS7500, DS8500, H8, M5, M5S, M8BT, M8BTS, NT-91
Questions
- How to set the slave address?
- Where is the slave address configuration barcode?
- How to adjust the slave address parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
Note: The factory default slave address is 0x00. Customers need to configure it to other addresses (1-255) before it can be used. Scan the slave address configuration barcode, and then scan the three-digit configuration barcode, the decimal slave address (1-255).
For example, to set the slave address to 0x0A (10), you need to scan the three-digit configuration barcode of 0, 1, 0 in order to set the address to 10 (0x0A)
Set slave address
Scan the following barcode to set the slave address.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
