This article introduces the setting method of "Set the starting position of retaining intermediate data", which is suitable for scenarios where you need to adjust the parameters related to "Custom barcode data retention" or scan the corresponding configuration barcode.
Applicable to:
F16, F18W, K20, K28, L5, L5S, L8, L8BL, L8BLS, L8S, M60, M80, NT-1228BL, S5, S8, Z2S, C750, W22, W28, DS8100, DS2800, DS7500, DS8500, H8, M5, M5S, M8BT, M8BTS, NT-91
Questions
- How to set the starting position of retaining intermediate data?
- Where is the starting position configuration barcode for retaining intermediate data?
- How to adjust the starting position parameter of retaining intermediate data?
Resolution / Answer
This setting is used to intercept, hide, insert or replace the scanned code data content. It is usually used when only part of the barcode content needs to be uploaded, useless characters need to be removed, or the business system requires a fixed data format.
Configure the starting position of retained intermediate data, ranging from 1-9999. After scanning the current barcode, scan the fixed 4-digit configuration barcode (decimal value). For example, if you want to retain the data after the 15th byte character (beginning with the 16th character), scan the numeric configuration barcode sequentially: 0 0 1 5.
Set the starting position of retaining intermediate data
Scan the following barcode to set the starting position for retaining intermediate data.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
