This article introduces the setting method of "Set the length of retained intermediate data", which is suitable for scenarios where you need to adjust the parameters related to "Custom barcode data retention" or scan the corresponding configuration barcode.
Applicable to:
F16, F18W, K20, K28, L5, L5S, L8, L8BL, L8BLS, L8S, M60, M80, NT-1228BL, S5, S8, Z2S, C750, W22, W28, DS8100, DS2800, DS7500, DS8500, H8, M5, M5S, M8BT, M8BTS, NT-91
Questions
- How to set the length of retained intermediate data?
- Where is the length configuration barcode for retaining intermediate data?
- How to adjust the length parameter of retained intermediate data?
Resolution / Answer
This setting is used to intercept, hide, insert or replace the scanned code data content. It is usually used when only part of the barcode content needs to be uploaded, useless characters need to be removed, or the business system requires a fixed data format.
Configure the length of retained intermediate data, ranging from 1-9999. After scanning the current barcode, scan the fixed 4-digit numeric configuration barcode (decimal value). For example, if you want to retain the data of 15 bytes from the starting position, scan the numeric configuration barcode sequentially: 0 0 1 5.
Set the length of retained intermediate data
Scan the following barcode to set the length of retained intermediate data.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
