This article introduces the setting method of "Set the length of retained header data", which is suitable for scenarios where you need to adjust the relevant parameters of "Custom barcode data retention" or scan the corresponding configuration barcode.
Applicable to:
F16, F18W, K20, K28, L5, L5S, L8, L8BL, L8BLS, L8S, M60, M80, NT-1228BL, S5, S8, Z2S, C750, W22, W28, DS8100, DS2800, DS7500, DS8500, H8, M5, M5S, M8BT, M8BTS, NT-91
Questions
- How to set the length of retained header data?
- Where is the length configuration barcode for retaining header data?
- How to adjust the length parameter of retained header data?
Resolution / Answer
This setting is used to intercept, hide, insert or replace the scanned code data content. It is usually used when only part of the barcode content needs to be uploaded, useless characters need to be removed, or the business system requires a fixed data format.
Configure the length of retained header data, ranging from 1-9999. After scanning the current barcode, scan the fixed 4-digit numeric configuration barcode (decimal value). For example, if you need to retain 15 byte characters, scan the numeric configuration barcode sequentially: 0 0 1 5.
Set the length of retained header data
Scan the following barcode to set the length of retained header data.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
