This article introduces the setting method of "UCC/EAN-128 length setting", which is suitable for scenarios where you need to adjust "GS1-128 (original UCC/EAN-128)" related parameters or scan the corresponding configuration barcode.
Applicable to:
F16, F18W, K20, K28, L5, L5S, L8, L8BL, L8BLS, L8S, M60, M80, NT-1228BL, S5, S8, Z2S, C750, W22, W28, DS8100, DS2800, DS7500, DS8500, H8, M5, M5S, M8BT, M8BTS, NT-91
Questions
- How to set UCC/EAN-128 length?
- Where is the UCC/EAN-128 length configuration barcode?
- How to adjust the UCC/EAN-128 length parameters?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Allows reading of UCC/EAN-128 codes of specific length. First scan the length barcode within a specific range, and then scan the 4-digit configuration barcode in the appendix to set the corresponding two sets of lengths L1 and L2. L1 and L2 each occupy a two-digit configuration barcode. If there are less than two digits, fill them with 0s.
To read UCC/EAN-128 codes of any length, just scan any length, no need to scan the numeric configuration barcode. Default: 0-99, setting range: 01-99.
(1) When L1<L2, L1 is the minimum length and L2 is the maximum length
(2) When L1>L2, L1 is the maximum length and L2 is the minimum length
(3) When L1=L2, read only fixed length (L1/L2)
For example:
It is only allowed to read 4-8 characters in length, then scan the number configuration barcode "0" "4" "0" "8" or "0" "8" "0" "4" to read the fixed length of 12 characters, then scan the number configuration barcode "1" "2" "1" "2"
Length within a specific range
Scan the following barcode for a specific range of lengths.
Any length
Scan the following barcode, of any length.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
