This article introduces the setting method of "Discrete 2 of 5 length setting", which is suitable for scenarios where you need to adjust the relevant parameters of "Discrete 2 of 5/Industrial 2 of 5/IND25/Industrial 25 code" or scan the corresponding configuration barcode.
Applicable to:
F16, F18W, K20, K28, L5, L5S, L8, L8BL, L8BLS, L8S, M60, M80, NT-1228BL, S5, S8, Z2S, C750, W22, W28, DS8100, DS2800, DS7500, DS8500, H8, M5, M5S, M8BT, M8BTS, NT-91
Questions
- How to set Discrete 2 of 5 length?
- Where is the Discrete 2 of 5 length configuration barcode?
- How to adjust the length parameter of Discrete 2 of 5?
Resolution / Answer
This article introduces the use and configuration method of "Discrete 2 of 5 length". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
Allows reading of Discrete 2 of 5 codes of a specific length. First scan the length barcode within a specific range, and then scan the 4-digit configuration barcode in the appendix to set the corresponding two sets of lengths L1 and L2. L1 and L2 each occupy a two-digit configuration barcode. If there are less than two digits, fill them with 0s.
To read Discrete 2 of 5 codes of any length, just scan any length, no need to scan the digital configuration barcode.
Default: 4-99, setting range: 01-99.
(1) When L1<L2, L1 is the minimum length and L2 is the maximum length
(2) When L1>L2, L1 is the maximum length and L2 is the minimum length
(3) When L1=L2, read only fixed length (L1/L2)
For example:
Only 4-8 characters are allowed to be read, so scan the number configuration barcode "0" "4" "0" "8" or "0" "8" "0" "4". Only 12 characters are allowed to be read, so scan the number configuration barcode "1" "2" "1" "2"
D 2 of 5 - length within a specific range
Scan the following barcode, D 2 of 5 - length within a specific range.
Any length - Scan this to decode D 2 of 5 encoding containing any characters. Note: Selecting this option may result in incorrect decoding of D 2 of 5.
D 2 of 5 - any length
Scan the following barcode, D 2 of 5 - any length.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
