This article introduces the setting method of "Matrix 25 length setting", which is suitable for scenarios where you need to adjust the relevant parameters of "Matrix 25 (Matrix 25)" or scan the corresponding configuration barcode.
Applicable to:
F16, F18W, K20, K28, L5, L5S, L8, L8BL, L8BLS, L8S, M60, M80, NT-1228BL, S5, S8, Z2S, C750, W22, W28, DS8100, DS2800, DS7500, DS8500, H8, M5, M5S, M8BT, M8BTS, NT-91
Questions
- How to set Matrix 25 length?
- Where is the Matrix 25 length configuration barcode?
- How to adjust the length parameter of Matrix 25?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Allows reading of Matrix 25 codes of a specific length. First scan the length barcode within a specific range, and then scan the 4-digit configuration barcode in the appendix to set the corresponding two sets of lengths L1 and L2. L1 and L2 each occupy a two-digit configuration barcode. If there are less than two digits, fill them with 0s. To read Matrix 25 codes of any length, just scan any length, no need to scan the numeric configuration barcode. Default: 4-99, setting range: 01-99.
(1) When L1<L2, L1 is the minimum length and L2 is the maximum length
(2) When L1>L2, L1 is the maximum length and L2 is the minimum length
(3) When L1=L2, read only fixed length (L1/L2)
For example:
Only 4-8 characters are allowed to be read, so scan the number configuration barcode "0" "4" "0" "8" or "0" "8" "0" "4". Only 12 characters are allowed to be read, so scan the number configuration barcode "1" "2" "1" "2"
Matrix 25 - Length within a specific range
Scan the following barcode, Matrix 25 - length within a specific range.
Any length - Scan this to decode Matrix 25 encodings containing any characters. Note: Selecting this option may result in incorrect Matrix 25 decoding.
Matrix 25 - any length
Scan the following barcode, Matrix 25 - any length.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
