This article introduces the setting method of "MSI Length Setting", which is suitable for scenarios where you need to adjust "MSI/MSI PLESSEY" related parameters or scan the corresponding configuration barcode.
Applicable to:
F16, F18W, K20, K28, L5, L5S, L8, L8BL, L8BLS, L8S, M60, M80, NT-1228BL, S5, S8, Z2S, C750, W22, W28, DS8100, DS2800, DS7500, DS8500, H8, M5, M5S, M8BT, M8BTS, NT-91
Questions
- How to set MSI length?
- Where is the MSI length configuration barcode?
- How to adjust the MSI length parameter?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Allows reading MSI codes of a specific length. First scan the length barcode within a specific range, and then scan the 4-digit configuration barcode in the appendix to set the corresponding two sets of lengths L1 and L2. L1 and L2 each occupy a two-digit configuration barcode. If there are less than two digits, fill them with 0s.
To read MSI codes of any length, just scan any length, no need to scan the numeric configuration barcode.
Default: 2-99, setting range: 01-99.
(1) When L1<L2, L1 is the minimum length and L2 is the maximum length
(2) When L1>L2, L1 is the maximum length and L2 is the minimum length
(3) When L1=L2, read only fixed length (L1/L2)
For example:
Only 4-8 characters are allowed to be read, so scan the number configuration barcode "0" "4" "0" "8" or "0" "8" "0" "4". Only 12 characters are allowed to be read, so scan the number configuration barcode "1" "2" "1" "2"
MSI - Length within a specific range
Scan the following barcode, MSI - length within a specific range.
**Any length** - Scan this to decode the MSI Plessey encoding containing any characters. Note: Selecting this option may result in incorrect MSI decoding.
MSI - any length
Scan the following barcode, MSI - any length.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
