This article introduces the setting method of "Brackets Surrounded GS1 Application Identifiers (GS1AIs)", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How do I set brackets around GS1 Application Identifiers (GS1AIs)?
- Where are the bracketed GS1 Application Identifiers (GS1AIs) configuration barcodes?
- How to adjust the bracketed GS1 Application Identifiers (GS1AIs) parameters?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
When the GS1 application identifier is turned on, '( ' is added to the left and ')' is added to the right of the GS1 application identifier.
**[Prohibited]
Scan the following barcode to configure **[Prohibited].
[Enable]
Scan the following barcode to configure [Enable].
When the GS1 application identifier is turned on, the barcode data output is (01)00614141999996(10)10ABCEDF123456.
When the GS1 application identifier is turned off, the barcode data output is 01006141419999961010ABCEDF123456.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
