This article introduces the setting method of "Sensor Sensitivity", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set the sensor sensitivity?
- Where is the sensor sensitivity configuration barcode?
- How to adjust the sensor sensitivity parameters?
Resolution / Answer
This setting controls when the device starts scanning, how long it lasts, and how continuous scans are handled. It is usually adjusted when manual triggering, automatic sensing, avoiding repeated output or improving scanning response speed are required.
Sensitivity specifies how responsive the scanner is to changes in the scanned image when in sensing mode. This setting is only valid for sensing mode of decode mode. Custom sensitivity ranges from 1 to 20. Default is custom (2).
[Low]
Scan the following barcode to configure [Low].
BigMedium
Scan the following barcode to configure big [middle].
[High]
Scan the following barcode to configure [High].
[Enhancement]
Scan the following barcode to configure [Enhanced].
[Customize]
Scan the following barcode to configure [Customize].
Set the sensor sensitivity to 10 and read the following barcodes in sequence to set:
- Read "Startup Settings"
- Read "custom"
3. Data code "1", "0" (see Appendix - Data Code)
- Read "Save" (see Appendix - Save or Cancel)
- Read "Exit Settings"
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
