This article introduces the setting method of "Decoding Center Area", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set the decoding center area?
- Where is the decoding center locale code?
- How to adjust the decoding center area parameters?
Resolution / Answer
This article introduces the use and configuration method of "Decoding Center Area". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
u Full area decoding: Select the entire area of the captured image (the entire picture) for decoding, and only output the first barcode read.
u Center area decoding: The center position of the barcode must be in the set area to be successfully read. When there are multiple barcodes in the set area at the same time, only the first barcode read will be output (in this case, it is recommended to reduce the size of the central area).
u Aimed barcode decoding: Only the barcode targeted by the aiming light is read and decoded. If the aiming light is in the shape of a "cross", use the intersection of the two lines of the "cross" as the alignment point.
**[Full area decoding]
Scan the following barcode to configure **[Full area decoding].
[Central area decoding]
Scan the following barcode to configure [Center Area Decoding].
[Aimed barcode decoding]
Scan the following barcode to configure [Aimed Barcode Decoding].
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
