This article introduces the setting method of "Auto Sleep", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set up automatic sleep?
- Where is the automatic sleep configuration barcode?
- How to adjust automatic sleep parameters?
Resolution / Answer
This article introduces the purpose and configuration method of "Auto Sleep". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
After the automatic sleep setting is turned on, the device enters sleep mode when the scanner enters the idle state and reaches the sleep timeout condition. The physical serial port can wake up the device by sending serial port commands (the first packet of data is invalid and does not respond, it is recommended to send 0x3f) and triggering buttons. The USB communication interface only supports key wake-up.
**[Prohibited]
Scan the following barcode to configure **[Prohibited].
[Enable]
Scan the following barcode to configure [Enable].
__Set sleep timeout conditions__
__Sleep timeout condition__ is used to determine how long the scanner will be idle before entering sleep state. Setting range is 1 - 36000 seconds. Default is 15 seconds.
[Set sleep timeout conditions]
Scan the following barcode to [Set sleep timeout conditions].
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
