This article introduces the setting method of "Baud Rate", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set the baud rate?
- Where is the baud rate configuration barcode?
- How to adjust the baud rate parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
The baud rate is the number of bits transmitted per second in serial port data communication. The baud rate used by the scanner and the data receiving host must be consistent to ensure accurate data transmission. The scanner supports the baud rates listed below in bit/s. Default: 9600bps
[115200]
Scan the following barcode to configure [115200].
[57600]
Scan the following barcode to configure [57600].
[38400]
Scan the following barcode to configure [38400].
[19200]
Scan the following barcode to configure [19200].
[14400]
Scan the following barcode to configure [14400].
**[9600]
Scan the following barcode to configure **[9600].
[4800]
Scan the following barcode to configure [4800].
[2400]
Scan the following barcode to configure [2400].
[1200]
Scan the following barcode to configure [1200].
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
