This article introduces the setting method of "stop bit", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set stop bit?
- Where is the stop bit configuration barcode?
- How to adjust the stop bit parameters?
Resolution / Answer
This setting is used to configure the communication method or communication parameters between the device and the host. Usually when connecting to a computer, serial device, RS485/Modbus network or access control Wiegand system, you need to ensure that the parameters at both ends are consistent.
The stop bit is located at the last part of each byte transmitted and is used to mark that the transmission of this byte is completed and the reception of the next byte of data can begin.
The default setting is 1 stop bit. If you need to stop for a longer time, you can set 2 stop bits.
**[A stop bit]
Scan the following barcode to configure **[one stop bit].
[Two stop bits]
Scan the following barcode to configure [two stop bits].
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
