This article introduces the setting method of "One-dimensional barcode dual code", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set up dual codes for one-dimensional barcodes?
- Where is the one-dimensional barcode dual code configuration barcode?
- How to adjust the dual code parameters of one-dimensional barcode?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
One-dimensional barcode dual code: two one-dimensional barcodes arranged one above the other. The directions of the double codes should be consistent, the difference should be as small as possible, and the distance should be as close as possible. Dual code setting is divided into the following three setting modes.
u Only read a single one-dimensional barcode: the device only reads one one-dimensional barcode at a time;
u Only read dual one-dimensional barcodes: The device must detect dual one-dimensional barcodes at any time and send decoding information only after decoding both codes successfully. The order of sending is from top to bottom.
u Readable single and double one-dimensional barcodes: When reading the code, first detect whether the one-dimensional double code exists. If it exists and is decoded successfully, it will be sent as a double code, otherwise it will be treated as a single code.
**[Read only a single one-dimensional barcode]
Scan the following barcode to configure **[Only read a single one-dimensional barcode].
[Read only double one-dimensional barcodes]
Scan the following barcode to configure [only read double 1D barcode].
[Readable single and double one-dimensional barcodes]
Scan the following barcode to configure [readable single and double one-dimensional barcodes].
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
