This article introduces the setting method of "Coupon GS1 DataBar Output", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set Coupon GS1 DataBar output?
- Where is the output configuration barcode of Coupon GS1 DataBar?
- How to adjust the output parameters of Coupon GS1 DataBar?
Resolution / Answer
This setting is used to control the additional characters and output mode at the end of the scanned data or during the output process. It is usually used when you need to automatically wrap lines, jump to the next input box, or adjust the data output format after scanning the QR code.
When the coupon type is: UPC-A + GS1 Databar starting with 5,
When the GS1 Databar output function is turned on, the device only outputs the information in the GS1 Databar part.
When the GS1 Databar output function is turned off, the device information output situation refers to the settings in the "Coupon Connection" chapter.
**[Close]
Scan the following barcode to configure **[Close].
[Open]
Scan the following barcode to [Open].
When using the UPC-A Coupon function, please ensure that UPC-A is set to "Transmit System Characters" or "Transmit Country Code + System Characters". Please refer to the "UPC-A" chapter for the setting method.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
