This article introduces the setting method of "Code32 Pharmaceutical (PARAF)", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set up Code32 Pharmaceutical (PARAF)?
- Where is the Code32 Pharmaceutical (PARAF) setup code?
- How to adjust Code32 Pharmaceutical (PARAF) parameters?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Code 32 Pharmaceutical is a form of the Code 39 barcode used in Italian pharmacies. This barcode is also known as PARAF. The output format of Code 32 is: * + A + 8 digits + 1 check digit + *.
**[Prohibited]
Scan the following barcode to configure **[Prohibited].
[Enable]
Scan the following barcode to configure [Enable].
Code 32 Pharmaceutical can only be read if Code39 reading is enabled and there is no verification.
__Code32 prefix__
**[Prohibited]
Scan the following barcode to configure **[Prohibited].
[Enable]
Scan the following barcode to configure [Enable].
__Code32 start character and suffix terminator__
**[No transmission]
Scan the following barcode to configure **[Do not send].
[Transmission]
Scan the following barcode to [Send].
__Code32 check character__
**[No transmission]
Scan the following barcode to configure **[Do not send].
[Transmission]
Scan the following barcode to [Send].
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
