This article introduces the setting method of "Data Matrix dual code", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set Data Matrix dual code?
- Where is the Data Matrix dual code configuration barcode?
- How to adjust the Data Matrix dual code parameters?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Data Matrix dual code: Two Data Matrix barcodes arranged one above the other or left and right. The directions of the double codes should be consistent, the difference should be as small as possible, and the distance should be as close as possible. Dual code setting is divided into the following three setting modes.
u Only read a single Data Matrix code: the device only reads one Data Matrix barcode at a time;
u Only read double Data Matrix codes: The device must detect the Data Matrix double codes at any time and send decoding information only after decoding both codes successfully. The order of sending is from top to bottom or left to right.
u Readable single and double Data Matrix codes: When reading the code, first detect whether the Data Matrix double code exists. If it exists and is decoded successfully, it will be sent as a double code, otherwise it will be treated as a single code.
Big [Read only a single Data Matrix code]
Scan the following barcode to read [only a single Data Matrix code].
[Read only double Data Matrix codes]
Scan the following barcode to configure [Read only double Data Matrix codes].
[Readable single and double Data Matrix codes]
Scan the following barcode to configure [Readable Single and Double Data Matrix Codes].
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
