This article introduces the setting method of "Hanse Code Dual Code", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set dual Hanse code?
- Where is the Hansein code dual code configuration barcode?
- How to adjust the double code parameters of Hanseatic code?
Resolution / Answer
This article introduces the use and configuration method of "Hanse Code Dual Code". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
Hansein code double code: two Hansein codes arranged up and down or left and right. The directions of the double codes must be consistent, the difference should be as small as possible, and the distance should be as close as possible.
Dual code setting is divided into the following three setting modes.
u Only read a single Chinese Sensible code: The device only reads one Chinese Seal code at a time.
u Only read dual Hanseatic codes: At any time, the device must detect dual Chinese Seal codes in a code picture, and both codes must be successfully decoded before sending decoding information.
u Readable single and double Hanseatic codes: In a picture, when the device detects double Hanseatic codes and successfully decodes the double codes, it will send the double code decoding information, otherwise the picture will only be treated as a single code.
Dada[Only read a single Chinese character code]
Scan the following barcode to read [only a single Chinese Sensible code].
[Only read double Chinese code]
Scan the following barcode to configure [only read double Hanse code].
[Readable single and even Chinese characters]
Scan the following barcode to configure [readable single and even Chinese characters].
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
