This article introduces the setting method of "Clear Data Format", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set the clear data format?
- Where is the clear data formatting code?
- How to adjust the clear data format parameters?
Resolution / Answer
This setting is used to intercept, hide, insert, replace or format the scanned code data content. It is usually used when only part of the barcode content needs to be uploaded, useless characters need to be removed, or the business system requires a fixed data format.
There are two ways to clear the data format configuration. One is to read the "Clear All Data Format" configuration barcode to clear all data formats; the other is to first read the "Clear One Group of Data Format" configuration barcode, then read the numbered data code of the group of data formats that need to be cleared, and then read the "Save" configuration barcode to clear one of the four groups of data editing format configurations. For example, to clear "data format 2", first read the "clear a group of data formats" configuration barcode, then read the data code "2", and finally read "save".
[Clear all data formats]
Scan the following barcode to [Clear all data formats].
[Clear a set of data formats]
Scan the following barcode to [clear a set of data formats].
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
