This article introduces the setting method of "Move Command", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set move command?
- Where is the move command configuration barcode?
- How to adjust the movement command parameters?
Resolution / Answer
This article introduces the purpose and configuration method of "move command". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
__F5 moves the cursor several characters to the right__
Command format = F5nn (nn: 00-99, the number of characters the cursor moves to the right) moves the cursor nn characters to the right.
__F5 Example: Move cursor right and send barcode data__
In the above barcode, move the cursor 3 characters to the right, send all the barcode data on the right side of the cursor, and finally send a carriage return. Command string: F503F10D
Scan the following barcode. In the above barcode, move the cursor 3 characters to the right, send all barcode data to the right of the cursor, and finally send a carriage return. Command string: F503F10D.
F5: "Move the cursor several characters to the right" command
03: The number of characters the cursor moves to the right
F1: "Send all characters" command
0D: Hexadecimal value of carriage return
Output result: __4567890ABCDEFGHIJ<CR>__
__F6 Move the cursor several characters to the left__
Command format = F6nn (nn: 00-99, the number of characters the cursor moves to the left)
Move the cursor nn characters to the left.
__F7 moves the cursor to the starting position__
Command format=F7
Move the cursor to the left of the first character of the input message.
__EA moves the cursor to the end position__
Command format=EA
Move the cursor to the left of the last character of the input message.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
