This article introduces the setting method of "Data Format Edit Command", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set the data format editing command?
- Where is the configuration barcode for the data format editing command?
- How to adjust the data format editing command parameters?
Resolution / Answer
This setting is used to intercept, hide, insert, replace or format the scanned code data content. It is usually used when only part of the barcode content needs to be uploaded, useless characters need to be removed, or the business system requires a fixed data format.
Using the Data Format Editor is like moving a virtual cursor through the input data string. The following commands can be used to move the cursor to different positions, select, replace, insert data into the final output, etc. For the hexadecimal values involved in the command, refer to the "ASCII Code Table" in the appendix.
Initial cursor position: Points to the first byte of the original barcode information that has not been edited by the data format.
As shown in the above barcode, the initial cursor position is to the left of "1"
Scan the following barcode. For example, in the above barcode, the initial cursor position is to the left of "1".
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
