This article introduces the setting method of "Make Batch Barcode", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set up batch barcode production?
- Where is the configuration barcode for making batch barcodes?
- How to adjust the parameters for batch barcode production?
Resolution / Answer
This setting is used to control the reading, verification, length or output rules of the specified barcode type. It is usually used when certain types of barcodes cannot be scanned, the misreading rate is high, or when it is necessary to limit the reading of barcodes in specific formats.
Batch barcodes can use any symbology supported and enabled by the scanner. It is recommended to use 2D barcodes.
For example, you need to set and save: turn on the light, read codes in induction mode, modify the timeout for one code reading to 2 seconds, and prohibit reading of Interleaved 2 of 5 barcodes. The command is: "@ILLSCN1;SCNMOD2;ORTSET2000;I25ENA0;".
The PDF417 code with data "@ILLSCN1;SCNMOD2;ORTSET2000;I25ENA0" is as follows:
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
