This article introduces the setting method of "Decoding LED Behavior", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set decoding LED behavior?
- Where is the code to decode LED behavior settings?
- How to adjust the decoding LED behavior parameters?
Resolution / Answer
This article introduces the use and configuration method of "Decoding LED Behavior". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
Select one of the following options for the serial host to control the decoding LED's relationship to low-power modes:
- **LED off then power down (default)**: The decoding LED remains on for about 1.5 seconds before the scanner can enter low power mode.
- **Turn off decoding LED on power down**: The decoding LED remains on until the scanner enters low power mode. Allows the scanner to enter a low-power mode as quickly as possible while still keeping the LED lit.
- **Disable Decode LED**: Turn off the decode LED completely.
* LED turns off and then power off (02h)
Scan the following barcode to configure * LED will turn off and then power off (02h).
Turn off the decoding LED when power is off (01h)
Scan the following barcode to turn off the decoding LED (01h) during power outage.
Disable decoding LED (00h)
Scan the following barcode to disable the decoding LED (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
