This article introduces the setting method of "Enter Low Power Mode Delay", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the delay for entering low power mode?
- Where is the delay configuration barcode for entering low power mode?
- How to adjust the delay parameters for entering low power mode?
Resolution / Answer
This article introduces the purpose and configuration method of "Enter Low Power Mode Delay". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
This parameter sets how long the decoder remains active after decoding. After each scan session, the decoder waits this time before entering low-power mode.
* 1 second (11h)
Scan the following barcode, *1 second (11h).
5 seconds (15h)
Scan the following barcode for 5 seconds (15h).
1 minute (21h)
Scan the following barcode for 1 minute (21h).
5 minutes (25h)
Scan the following barcode for 5 minutes (25h).
15 minutes (2Bh)
Scan the following barcode, 15 minutes (2Bh).
1 hour (31h)
Scan the following barcode for 1 hour (31h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
