This article introduces the setting method of "Mirror Image", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up a mirror image?
- Where is the mirror image configuration barcode?
- How to adjust the mirror image parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
Enable this to reverse (mirror) scan the image as if viewed through a mirror. This mode is suitable for applications that require scanning through a mirror and use symbologys that do not support reverse decoding.
When enabled in photo, video or video viewfinder mode, the transferred image is also mirrored.
* Disable mirror image (00h)
Scan the following barcode, * Mirror image disabled (00h).
Enable mirror image (01h)
Scan the following barcode to enable mirroring (01h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
