This article introduces the setting method of "Picklist Mode", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set Picklist Mode?
- Where is the Picklist Mode configuration barcode?
- How to adjust the parameters of Picklist Mode?
Resolution / Answer
This article introduces the purpose and configuration method of "Picklist Mode". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
When picking mode is enabled, the decoder only decodes barcodes aligned with the center of the aiming pattern. Optional modes:
- **Always Disabled**: Picking mode is always off.
- **Always on**: Picking mode is always on.
* Always disabled (00h)
Scan the following barcode, * is always disabled (00h).
Always enabled (02h)
Scan the following barcode to always enable (02h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
