This article introduces the setting method of "Continuous Barcode Read", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up Continuous Barcode Read?
- Where is the Continuous Barcode Read configuration barcode?
- How to adjust the parameters of Continuous Barcode Read?
Resolution / Answer
This setting controls when the device starts scanning, how long it lasts, and how continuous scans are handled. It is usually adjusted when manual triggering, automatic sensing, avoiding repeated output or improving scanning response speed are required.
Enabling this option allows decoding processing to continue until the end of the trigger event or "Decoding Session Timeout" on page 6-20; the user will be prompted each time a barcode is decoded. Disabling this option will end the decoding process as soon as a valid decoding occurs. This mode is not available in demo mode.
* Disable continuous code reading (00h)
Scan the following barcode, * Continuous reading is disabled (00h).
Enable continuous code reading (01h)
Scan the following barcode to enable continuous reading (01h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
