This article introduces the setting method of "Scan Data Transmission Format", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the scan data transmission format?
- Where is the scan data transfer format configuration barcode?
- How to adjust the scanning data transmission format parameters?
Resolution / Answer
This setting is used to intercept, hide, insert, replace or format the scanned code data content. It is usually used when only part of the barcode content needs to be uploaded, useless characters need to be removed, or the business system requires a fixed data format.
To change the scanned data format, scan the barcode corresponding to the desired format among the eight barcodes below.
Note: Do not use ADF rules to set prefix/suffix when using this parameter.
To set the specific value of prefix/suffix, see "Prefix/Suffix Values" on page 6-29.
* Data as is (00h)
Scan the following barcode, * data as is (00h).
<DATA> <SUFFIX 1>(01h)
Scan the following barcode, <DATA> <SUFFIX 1> (01h).
<DATA> <SUFFIX 2>(02h)
Scan the following barcode, <DATA> <SUFFIX 2> (02h).
<DATA> <SUFFIX 1> <SUFFIX 2>(03h)
Scan the following barcode, <DATA> <SUFFIX 1> <SUFFIX 2> (03h).
<PREFIX> <DATA>(04h)
Scan the following barcode, <PREFIX> <DATA> (04h).
<PREFIX> <DATA> <SUFFIX 1>(05h)
Scan the following barcode, <PREFIX> <DATA> <SUFFIX 1> (05h).
<PREFIX> <DATA> <SUFFIX 2>(06h)
Scan the following barcode, <PREFIX> <DATA> <SUFFIX 2> (06h).
<PREFIX> <DATA> <SUFFIX 1> <SUFFIX 2>(07h)
Scan the following barcode, <PREFIX> <DATA> <SUFFIX 1> <SUFFIX 2> (07h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
