This article introduces the setting method of "different symbol decoding intervals", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the decoding interval for different symbols?
- Where are the codes for setting the decoding intervals of different symbols?
- How to adjust the decoding interval parameters for different symbols?
Resolution / Answer
This article introduces the use and configuration method of "different symbol decoding intervals". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
Use this option in demo mode or continuous decode mode to control the amount of time the decoder is inactive between decoding different symbols. Can be set from 0.1 to 9.9 seconds in 0.1 second steps. Default is 0.2 seconds.
To set a different symbol decoding interval, scan the barcode below, then scan the two-digit barcode in 0.1-second increments from Appendix D, "Numeric Barcodes."
Different symbol decoding intervals
Scan the following barcode to configure with different symbol decoding intervals.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
