This article introduces the setting method of "Demo Mode Field of View Range", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the field of view in demo mode?
- Where is the code for setting the field of view range in demo mode?
- How to adjust the field of view parameters in demonstration mode?
Resolution / Answer
This article introduces the use and configuration method of "Demonstration Mode Field of View Range". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
In demo mode, the decoder searches for the barcode in the area around the center of the aiming pattern.
If you want to speed up the search, you can select "Small field of view" to narrow the search range; if you want to search a larger area, select "Full field of view".
Small field of view (00h)
Scan the following barcode, Small Field of View (00h).
* Medium field of view (01h)
Scan the following barcode, * Medium Field of View (01h).
Full field of view (02h)
Scan the following barcode, Full Field of View (02h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
