This article introduces the setting method of "PDF Prioritization", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set PDF Prioritization?
- Where is the PDF Prioritization configuration barcode?
- How to adjust PDF Prioritization parameters?
Resolution / Answer
This article introduces the purpose and configuration method of "PDF Prioritization". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
When enabled, decoding of 1D barcodes (Code 128 with a length of 8 to 25 characters) is delayed by the time specified by the PDF Prioritization Timeout. During this period, the decoder attempts to decode PDF417 symbols (such as a US driver's license), and if successful, only reports PDF417; if no PDF417 symbols are found, a 1D code is reported after a timeout. The QR code must still be within the device's field of view to be reported. This parameter does not affect the decoding of other symbologys.
* Disable PDF priority (00h)
Scan the following barcode, * Disable PDF priority (00h).
Enable PDF priority (01h)
Scan the following barcode to enable PDF priority (01h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
