This article introduces the setting method of "PDF priority timeout", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set PDF priority timeout?
- Where is the PDF priority timeout configuration barcode?
- How to adjust the PDF priority timeout parameter?
Resolution / Answer
This article introduces the purpose and configuration method of "PDF Priority Timeout". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
When PDF priority is enabled, this timeout specifies how long the decoder attempts to decode PDF417 symbols before reporting a 1D barcode in the field of view.
Scan the barcode below, then scan the 4-digit number from Appendix D, "Numeric Barcodes," to specify the number of milliseconds. For example, to set it to 400 ms, scan the barcode below and then scan 0, 4, 0, 0. Range 0 to 5000 ms, default 200 ms.
PDF priority timeout
Scan the following barcode, PDF priority times out.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
