This article introduces the setting method of "Aiming Brightness", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set aiming brightness?
- Where is the aiming brightness configuration barcode?
- How to adjust the aiming brightness parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
This function sets the brightness of the aiming pattern. The default value is 0, which means the aiming pattern is always lit between camera exposures. When the value is greater than 0, the aiming duration increases by 0.5 ms for every 1 increase in the brightness value.
To set the aiming brightness, scan the barcode below, then scan the three-digit numeric barcode corresponding to the brightness value from Appendix D "Numeric Barcodes". The value range is 0-255. The maximum aim duration is limited by frame time, so the recommended range is 0-30 when the frame rate is set to 60 fps.
Aim for brightness
Scan the following barcode to aim for brightness.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
