This article introduces the setting method of "Lighting Brightness", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set lighting brightness?
- Where is the lighting brightness configuration barcode?
- How to adjust lighting brightness parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
This function sets the lighting brightness by changing the LED power. The default value is 10, which is the maximum LED brightness. Values between 1-10 range from lowest to highest LED brightness.
To set the lighting brightness, scan the barcode below, then scan the two-digit barcode from Appendix D "Numeric Barcodes" that corresponds to the desired brightness value. For example, to set the lighting brightness to 6, scan the barcode below and then scan 0 and 6.
Lighting brightness
Scan the following barcode for lighting brightness.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
