This article introduces the setting method of "Frame Rate", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set frame rate?
- Where is the frame rate configuration barcode?
- How to adjust the frame rate parameters?
Resolution / Answer
This article introduces the use and configuration method of "frame rate". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
Select an option to control the rate at which frames are captured and transferred. When capturing images, using a lower frame rate can improve image brightness.
NOTE: The aiming pattern will appear to flicker when the frame rate is 30 fps or lower.
Frame rate settings:
- **Auto**: PL3307 controls the frame rate and dynamically changes it based on the working mode to provide the best performance.
- **60 fps**: Fixed 60 frames/second
- **55 fps**: Fixed 55 frames/second
- **50 fps**: Fixed 50 frames/second
- **45 fps**: Fixed 45 frames/second
- **40 fps**: Fixed 40 frames/second
- **30 fps**: Fixed 30 frames/second
- **20 fps**: Fixed 20 frames/second
- **15 fps**: Fixed 15 frames/second
- **10 fps**: Fixed 10 frames/second
* Automatic (00h)
Scan the following barcode, * Automatic (00h).
60 fps(01h)
Scan the following barcode, 60 fps (01h).
55 fps(05h)
Scan the following barcode, 55 fps (05h).
50 fps(06h)
Scan the following barcode, 50 fps (06h).
45 fps(07h)
Scan the following barcode, 45 fps (07h).
40 fps(08h)
Scan the following barcode, 40 fps (08h).
30 fps(02h)
Scan the following barcode, 30 fps (02h).
20 fps(09h)
Scan the following barcode, 20 fps (09h).
15 fps(03h)
Scan the following barcode, 15 fps (03h).
10 fps(04h)
Scan the following barcode, 10 fps (04h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
