This article introduces the setting method of "LED lighting", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up LED lighting?
- Where is the LED lighting setup code?
- How to adjust LED lighting parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
Choose the type of LED lighting you want to use:
- **Internal Lighting**: Use the engine's own lighting.
- **External Illumination**: The ILLUM_EN_OUT signal is continuously asserted during the decoding session and engine illumination is not used.
- **Internal and external lighting**: Use engine lighting and keep asserting the ILLUM_EN_OUT signal during the decoding session.
- **Internal Illumination Matching Engine (SE4500 only)**: Using engine illumination, the ILLUM_EN_OUT signal is pulsed every frame to match the engine illumination duration. NOTE This option is not supported on SE3300.
- **Internal and External Lighting Alternate (SE4500 only)**: Use engine lighting on alternating frames with the ILLUM_EN_OUT signal. NOTE This option is not supported on SE3300.
This parameter is effective for decoding only when "Decoding Illumination" on page 7-12 is enabled; this parameter is effective for image acquisition only when "Image Acquisition Illumination" on page 7-14 is enabled. Disabling any item will turn off all lighting in the corresponding mode, regardless of how this "LED Lighting" is set.
* Internal lighting (00h)
Scan the following barcode, * Internal Lighting (00h).
External lighting (01h)
Scan the following barcode to configure External Lighting (01h).
Internal and external lighting (02h)
Scan the following barcode for internal and external lighting (02h).
Internal Lighting Matching Engine (SE4500 only) (04h)
Scan the following barcode, Internal Lighting Matching Engine (SE4500 only) (04h).
Alternating internal and external lighting (SE4500 only) (05h)
Scan the following barcode, Alternating internal and external lighting (SE4500 only) (05h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
