This article introduces the setting method of "exposure time", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set exposure time?
- Where is the exposure time configuration barcode?
- How to adjust the exposure time parameters?
Resolution / Answer
This article introduces the use and configuration method of "exposure time". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
This parameter only takes effect when decoding or image acquisition auto-exposure is disabled. It configures exposure for both decoding mode and photo-taking mode.
Each integer value represents an exposure of 100 ?s. The default value is 100, which corresponds to a 10 ms exposure.
Note: The maximum exposure time is determined by the configured frame rate. For example, the maximum exposure time allowed at 60 fps is 15 ms. When the setting exceeds the allowed value of the frame rate, the allowed maximum value will be automatically taken.
The longer the exposure time, the lower the aiming brightness.
To set the exposure time, scan the "Fixed Exposure" barcode, then scan the 4-digit barcode representing the numerical value (1-1000) from Appendix D, "Numeric Barcodes." Leading zeros are added when necessary. For example, to set it to 9.9 ms, scan 0, 0, 9, 9.
Exposure time (4 digits)
Please scan the appropriate barcode, exposure time (4 digits) below.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
