This article introduces the setting method of "image acquisition automatic exposure", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set automatic exposure for image acquisition?
- Where is the image acquisition automatic exposure configuration barcode?
- How to adjust the automatic exposure parameters of image acquisition?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
Selecting "Enable image capture automatic exposure" allows the decoder to control the gain and exposure (integration) time to optimally capture images in photo mode.
Select "Disable automatic exposure for image acquisition" to manually adjust gain and exposure time (see "Fixed gain" and "Exposure time"). Motorola only recommends this option for advanced users in special scenarios where acquisition is difficult.
* Enable image acquisition automatic exposure (01h)
Scan the following barcode to* enable automatic exposure for image capture (01h).
Disable image acquisition automatic exposure (00h)
Scan the following barcode to disable image capture auto-exposure (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
