This article introduces the setting method of "Image Cropping", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set image cropping?
- Where is the image cropping configuration barcode?
- How to adjust image cropping parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
This parameter crops the collected image. Selecting "Disable Image Cropping" will output a complete 752×480 pixel image; selecting "Enable" will crop the image according to the pixel address set in "Crop to Pixel Address" on page 7-17.
NOTE: The decoder's crop resolution is 4 pixels. If the crop area is set to less than 3 pixels, the entire image will be transferred.
Enable image cropping (01h)
Scan the following barcode to enable image cropping (01h).
* Disable image cropping (use full 752×480 pixels) (00h)
Scan the following barcode, * Disable image cropping (use full 752×480 pixels) (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
