This article introduces the setting method of "Decoding Aiming Pattern", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the decoding aiming pattern?
- Where is the decoded aiming pattern configuration barcode?
- How to adjust the decoding aiming pattern parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
Select "Enable Decoded Aiming Pattern" to project the aiming pattern during barcode capture, or "Disable Decoded Aiming Pattern" to turn it off.
* Enable decoded aiming pattern (02h)
Scan the following barcode to* enable the decoded aiming pattern (02h).
Disable decoded aiming pattern (00h)
Scan the following barcode to disable decoding the aiming pattern (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
