This article introduces the setting method of "Image Acquisition Lighting", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up lighting for image acquisition?
- Where is the image acquisition lighting setup code?
- How to adjust the lighting parameters for image acquisition?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
Selecting "Enable Image Acquisition Illumination" turns on illumination with every image acquisition. Disabling lighting means no lighting is used.
Enabling lighting usually results in better images. As the distance from the target increases, the effectiveness of the lighting decreases.
* Enable image acquisition lighting (01h)
Scan the following barcode to* enable image capture lighting (01h).
Disable image acquisition lighting (00h)
Scan the following barcode to disable image capture lighting (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
