This article introduces the setting method of "Photography Mode Timeout", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set the photo mode timeout?
- Where is the photo mode timeout configuration barcode?
- How to adjust the photo mode timeout parameters?
Resolution / Answer
This article introduces the purpose and configuration method of "Photo Mode Timeout". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
This parameter sets the length of time the decoder stays in camera mode. The decoder will exit this mode due to a trigger event or the expiration of the photo mode timeout. To set this timeout value, scan the barcode below, and then scan a numeric barcode in Appendix D, "Numeric Barcodes." The default value is 0, which corresponds to 30 seconds; each increment of 1 adds 30 seconds. For example, 1 = 60 seconds, 2 = 90 seconds, and so on.
Photo mode timeout
Scan the following barcode. The photo mode has timed out.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
