This article introduces the setting method of "Crop to Pixel Address", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set crop to pixel address?
- Where is the crop to pixel address configuration barcode?
- How to adjust the crop to pixel address parameters?
Resolution / Answer
This article introduces the use and configuration method of "Crop to Pixel Address". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
If image cropping is enabled, you can set the pixel address in the range (0,0) to (751,479) for cropping.
Column numbers 0-751, row numbers 0-479. Specify 4 values: top, left, bottom, right, where "top" and "bottom" correspond to row pixel addresses, and "left" and "right" correspond to column pixel addresses. For example, to crop an area of 4 rows × 8 columns in the lower right corner of the image, set the following settings:
Top = 476, Bottom = 479, Left = 744, Right = 751
To set the clipping pixel address, scan the appropriate "Pixel Address" barcode below, then scan the 3-digit barcode representing the value from Appendix D "Numeric Barcodes". Leading zeros need to be padded, for example, to enter 3, scan 0, 0, 3.
Note: The minimum crop resolution of the decoder is 4 pixels; crop addresses should be incremented/decremented in multiples of 4, other values will be rounded up. For example, cropping from top address 0, 1, or 2 (that is, removing 1, 2, or 3 pixels) has the same effect as cropping from address 3 - both will remove 4 lines from the top.
Top pixel address (0-479 decimal)
Scan the following barcode, with the top pixel address (0-479 decimal).
Left pixel address (0-751 decimal)
Scan the following barcode, pixel address (0-751 decimal) on the left.
Bottom pixel address (0-479 decimal)
Scan the following barcode, bottom pixel address (0-479 decimal).
Right pixel address (0-751 decimal)
Scan the following barcode, pixel address (0-751 decimal) to the right.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
