This article introduces the setting method of "JPEG quality value and size value", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set JPEG quality value and size value?
- Where are the JPEG quality and size configuration barcodes?
- How to adjust JPEG quality value and size value parameters?
Resolution / Answer
This article introduces the use and configuration method of "JPEG quality value and size value". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
**JPEG quality parameter # F0h 31h; JPEG size parameter # F1h 31h**
If you select "JPEG Quality Priority", scan the "JPEG Quality Value" barcode, and then scan the 3-digit barcode representing a value from 5-100 (100 represents the highest quality) from Appendix D "Numeric Barcodes".
If you select "JPEG Size Priority", scan "JPEG Size Value", and then scan the 3-digit numeric barcode from Appendix D "Digital Barcode" representing a value of 5-350, in multiples of 1024 bytes (1K). For example, if set to 8 (008), the file size can reach 8192 bytes.
JPEG quality value (default 065, 5-100 decimal)
Scan the following barcode for the JPEG quality value (default 065, 5-100 decimal).
JPEG size value (default 160, 5-350 decimal)
Scan the following barcode for the JPEG size value (default 160, 5-350 decimal).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
