This article introduces the setting method of "Image Enhancement", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up image enhancement?
- Where is the image enhancement configuration barcode?
- How to adjust image enhancement parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
This feature combines edge sharpening with contrast enhancement to produce a more visually pleasing image. If you select "User-defined", you also need to set "Image edge sharpening" on page 7-24 and "Image contrast enhancement" on page 7-25.
Image enhancement level:
- Close(0)
- Low (1) - Default
- Medium (2)
- High (3)
- User-defined (4)
Close (0)
Scan the following barcode to close (0).
* Low (1)
Scan the following barcode, * low (1).
Medium (2)
Scan the following barcode, center (2).
High (3)
Scan the following barcode, high (3).
User-defined (4)
Scan the following barcode to configure user-defined (4).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
