This article introduces the setting method of "Image Edge Sharpening", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set image edge sharpening?
- Where is the image edge sharpening configuration barcode?
- How to adjust image edge sharpening parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
This function uses edge sharpening technology and is only effective when "Image Enhancement" is set to "User-defined". To set this parameter, scan the "Image Edge Sharpening" barcode, then scan the 3-digit barcode representing the sharpening value from Appendix D "Numeric Barcodes". Or scan one of the recommended value barcodes below.
Recommended settings:
- Close(0)
- Low (30) - Default
- Medium (75)
- High (100)
Image edge sharpening
Scan the following barcode to sharpen the edges of the image.
Close (0)
Scan the following barcode to close (0).
* Low (30)
Scan the following barcode, * low (30).
Medium (75)
Scan the following barcode, center (75).
High (100)
Scan the following barcode, high (100).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
