This article introduces the setting method of "Image Resolution", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set image resolution?
- Where is the image resolution configuration barcode?
- How to adjust the image resolution parameters?
Resolution / Answer
This setting controls the device's sound, lighting, aiming, or image-related feedback. It is usually used when you need to reduce the beep sound, confirm the scanning status, improve lighting positioning, or adjust the image reading effect.
This option changes the image resolution before compression. The rows and columns are removed from the image, resulting in a smaller image with the original content but at a lower resolution.
Optional values:
Resolution value Uncropped image size
Full resolution 752 × 480
1/2 376 × 240
1/4 188 × 120
* Full resolution (00h)
Scan the following barcode, * full resolution (00h).
1/2 resolution (01h)
Scan the following barcode, 1/2 resolution (01h).
1/4 resolution (03h)
Scan the following barcode, 1/4 resolution (03h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
